EVH 系列 70Vdc保險絲設計用于高達500A的大電流電路保護
具有6kA分斷能力，可為電池、其他重載電纜等
Rated Voltage: 70VDC
Rated Current: 60A ~ 500A
Interrupting Rating: 6000A@70VDC (TC=2±0.5ms)
Operating Temperature Range: -40℃~125℃
Housing Material: PPA-GF33 Terminals:
Copper(Matt Tin Plated) Mounting Torque M8: 20Nm±1Nm
Standard Reference: ISO20934-2019(Type SF51)
RoHS Compliant
